12V CWP Series WaterProof Power Supply

POWER SUPPLY > WaterProof Power Supply > 12V CWP Series WaterProof Power Supply

12V CWP Series WaterProof Power Supply

These are excellent quality CE/RoHS/FCC Listed CWP Series 12V Waterproof power supplies that can be used for 12V LED strip lights and other LED lights in indoor and outdoor applications. The CWP Series IP67 Waterproof Power Supply has 2 bare wires to connect to your LED Lights.

Shampower CWP Series waterproof power supply 12VDC is suitable for installation in both North America and Europe. It accepts a wide range of input voltage, from 100 to 350VAC.

Available Wattage: 10W to 400W

12V CWP Series IP67 Waterproof Power Supply Features：

1) frosted silver high-quality anodized aluminum construction

2) High-density double-sided fiberglass PCB with SMT process

3) 10W to 400W is available

4) IP67 waterproof performance

5) Superior heat dissipation with a fanless silent design

6) Short circuit, overload, overvoltage, overcurrent, and leakage protection

7) CE & RoHS & FCC & ISO9001 listed

8) ODM & OEM supported and Fast delivery

9) Three years warranty

12V CWP Series IP67 Waterproof Power Supply Specifications:

DC Output	DC Voltage: 12V/24V
	Ripple & Noise: 80MV
	DC Adjustable Range: ±10% Rated Voltage
	Voltage Tolerance: ±2.0%
	Line Regulation: ±0.5%
	Load Regulation: ±1%
	Setup, Rise Time, Hold Up Time:200ms, 50ms, 20ms/230VAC
AC Input	AC Voltage Range: 85-264VAC
	Frequency Range: 47-63Hz
	Efficiency:90%
	AC Current: 0.86/115V 0.4A/230V
	AC Inrush Current: 20A/115V 40A/230V
	Leakage Current< 0.5mA /240VAC
Protection	Over-load: 105%-150% hiccup mode, Auto-recovery
	Over-voltage: 115%-135% Cut Off the Output, Auto-recovery
	Over-temp. : Shut down O/P voltage, Auto-recovery
Environment	Working temp.: -10~ +60°C (Refer to output load derating curve)
	Working Humidity:20 ~ 90% RH, non-condensing
	Storage Temp.: -10~ +60°C
	Storage Humidity: 10 ~ 95% RH
Safety	Isolation Resistance:I/P-O/P,I/P-FG,O/P-FG:100M Ohms/500VDC / 25C°/ 70% RH
	Withstand Voltage: I/P-O/P:3KVAC; I/P-FG:1.5KVAC; O/P-FG:0.5KVAC
	Safety standards: CE, RoHS, FCC, ISO9001

12V CWP Series IP67 Waterproof Power Supply Applications:

1) LED luminous characters

2) LED interior lighting

3) LED decorative lighting

4) LED advertising lighting

5) LED street lighting

6) LED architectural lighting

7) LED patio lights

8) LED floodlights

9) LED strip lighting

10) LED stage lighting

11) LED flash

12) LED Greenhouse Lighting

13) LED wall washer

14) LED Horticultural Lighting

15) Stadium lighting

16) LED fishing light

17) Port lighting

18) LED overhead lighting

19) LED parking lighting
