24V IP65 RPS Rainproof Power Supply

24V RPS rainproof LED power supply is converted from ac 110V / 220V input to dc 24v output.

24V RPS rainproof LED Transformer contains 60W, 120W, 150W, 200W, 300W, 400W, 500W, 600W, 700W, 800W, 900W, etc. Other specifications can be customized.

SHAMPOWER RPS rainproof LED Driver has passed CE, RoHS, BIS and FCC certifications.

24V RPS rainproof LED power supply is suitable for LED luminous characters, advertising light boxes, outdoor billboards, etc.

Available Outputs:

60W, 120W, 150W, 200W, 300W, 400W, 500W, 600W, 700W, 800W, 900W



24V RPS Rainproof LED Power Supply Features:

1) Available in wattage from 60W to 900W

2) Available in silver & gold finishes

3) Sturdy aluminium construction

4) IP65 waterproof performance

5) High-density double-side PCB with SMT process

6) More dust-proof, moisture-proof, salt proof of three anti-paint-soaked PCB

7) Superior heat dissipation with a built-in fan

8) BIS & CE & RoHS & FCC & ISO9001 listed

9) ODM & OEM supported and Fast delivery

10) Three years warranty



24V RPS Rainproof LED Power Supply Specifications

DC Output



Ripple & Noise: 80MV

DC Adjustable Range: ±10% Rated Voltage

Voltage Tolerance: ±2.0%

Line Regulation: ±0.5%

Load Regulation: ±1%

Setup, Rise Time, Hold Up Time: 200ms, 50ms, 20ms / 230VAC





AC Input







AC Voltage Range: 85-264VAC

Frequency Range: 47-63Hz

Efficiency: 90%

AC Current: 0.86/115V  0.4A / 230V

AC Inrush Current: 20A/115V   40A/230V

Leakage Current< 0.5mA / 240VAC



Protection



Over-load: 105%-150% hiccup mode, Auto-recovery

Over-voltage: 115%-135% Cut Off the Output, Auto-recovery

Over-temp.: Shut down O/P voltage, Auto-recovery



Environment





Working temp.: -10~ +60°C  (Refer to output load derating curve)

Working Humidity: 20 ~ 90% RH, non-condensing

Storage Temp.: -10~ +60°C

Storage Humidity: 10 ~ 95% RH



Safety



Withstand voltage: I/P-O/P: 3.0KVAC/1min; I/P-F/G: 1.5KVAC/1min; O/P-F/G: 0.5KVAC/1min

Safety standards: CE, RoHS, FCC, ISO9001,CCC



24V RPS Rainproof LED Power Supply Applications:

1) Industrial automation machinery

2) Industrial control system

3) Mechanical and electrical equipment

4) Electronic instruments, equipment or apparatus

5) Household appliances

6) LED display application

7) Power Source Equipment for PoE ( 55V model )
